Oil & Gas
Fuel Gas Conditioning & TEG Dehydration Package
Piping Stress Analysis – Critical Systems — Client: Process Group International (PGI), Abu Dhabi, UAE
Project Deliverable Photo / Model
Project Overview
Invictus Engineering executed comprehensive piping stress analysis for over 30 critical piping systems, involving high operating pressures and temperatures. The project presented multiple engineering challenges requiring detailed analysis and optimization of the piping support arrangements.
Scope of Work & Key Deliverables
Stress Analysis of 30+ Critical Piping Systems
Analysis of systems operating at critical pressures and temperatures
Evaluation and resolution of complex piping flexibility and support challenges
Optimization of piping support arrangements through rigorous engineering analysis
Minimized the requirement for special supports and spring hangers
Delivered safe, reliable and optimized piping systems while maintaining practical support arrangements
Core Technical Services Applied
CAESAR II Stress AnalysisHigh Pressure / Temperature System DesignPiping Flexibility OptimizationSupport & Spring Hanger MinimizationCode Compliance & Documentation
Project Metadata
Client
Process Group International (PGI), Abu Dhabi, UAE
Location
Turaif, Saudi Arabia
Duration & Status
Completed & Commissioned
Sector
Oil & Gas
